Build the Array
Select all
Clear
Clock sync ON
Active Stations
8 of 8
Longest Baseline
13,000 km
Image Quality
Ring emerging
Sync Status
Correlated
With all eight synchronized stations, the array reaches Earth-size class resolution and the ring structure becomes much clearer.
Participating Telescopes
Click a station to toggle it
Very-long-baseline interferometry
The EHT did not build a literal giant dish. It combined observations from telescopes spread across Earth so the array behaved like a much larger instrument. This technique works because radio waves can be recorded and compared later, unlike visible light.
Schwarzschild physics & the photon ring
The reconstruction uses real Schwarzschild metric calculations to model how gravity bends light near the black hole. The bright ring you see is light from hot material orbiting at the photon sphere, located 1.48 times the event horizon radius. This is the glow from matter spiraling into the black hole.
Accretion disk models & black-body radiation
Real black holes are surrounded by different disk types. A thin disk (Shakura–Sunyaev) orbits close and hot; a thick torus (ADAF) extends further and cooler; a slim disk occurs in super-Eddington accretion. Colors are based on black-body radiation: hotter material (blue-white) orbits closer, cooler material (orange-red) is further out. The lesson switches models as array quality improves.
Relativistic jets
Magnetic fields threading the accretion disk can launch jets of plasma at near-light speed perpendicular to the disk. These jets are visible at high array resolution as blue columns of light shooting from the black hole's poles. Jets are powered by the Blandford–Znajek mechanism and carry away rotational energy.
Atomic clocks and correlation
Each site timestamped its data using atomic clocks accurate to nanoseconds. Later, specialized computers called correlators aligned those recordings so the wave patterns could be combined instead of becoming meaningless noise. Without this synchronization, no image is possible.
What the image shows
The famous ring is glowing material orbiting the black hole. The darker center is the shadow region—the dark silhouette of the event horizon itself, where gravity is so strong that even light cannot escape. The asymmetry you see is from Doppler shift: material approaching us is brighter.
Why the first image mattered
The 2019 image of M87* and 2022 image of Sagittarius A* provided direct visual evidence of black hole-scale structure and proved that a global collaboration could use Earth itself as a telescope platform. It matched predictions from Einstein's general relativity.
Key concepts
Angular resolution is limited by wavelength and baseline length. Longer baselines resolve finer detail. Radio waves are much longer than visible light, so you need Earth-size baselines to see a black hole shadow.
Clock synchronization is absolutely critical. If stations aren't locked to the same time reference, the phase information is lost and no image can be reconstructed.
Photon bending happens because spacetime is curved by the black hole's mass. Light doesn't bend uniformly—it bends most sharply near the event horizon.
Black-body spectrum tells us the disk temperature from color. Hotter material emits in blue-white; cooler material glows orange-red. This matches real observations of M87* and Sagittarius A*.
